224-310KW广西顶博发电机组制造:康明斯发电用发动机可靠性高：高强度合金铸造缸体、可锻铸铁(FCD) 活塞，刚性更好，降低振动和噪声，提高了发动机适应更高的爆发压力。

High reliability: intensified alloy casting cylinder and Ferrous Cast Ductile (FCD) piston provide engine a better rigidity performance and lower vibration & noise, and also make the engine adapt to higher explosion pressure.

康明斯发电厂用打着机气油实惠性好: 先进性的气油操控操作系统的，独具特色的STC、ESTC 分级制度操控操作系统的，特异设计制作的柱塞边侧复燃室，髙压压喷射气油，全面雾化吸入，复燃全面。

Good fuel economy: Advanced fuel control system, unique STC, ESTC step control system, specilly-designed piston topchamber and high pressure fuel injection lead to an excellent fuel consumption rate and emission performance of engine.

康明斯生产发电用打火机瞬态能力优质: 圆满的打火机整体结构设计的，协调一致康明斯独特性的EFC设备，操纵gps精高，回应时刻快。

Excellent transient performance: perfect overall engine design with unique Cummins EFC system, high precision on control and quick response time.

康明斯风能发电用发起机升工作电压高: 建筑体设计构思紧凑型suv.外观设计安排合理安排，进行市场平稳。High lift power: Integrated and compact design, reasonable layout and smooth operation.

电喷车型 QSNT. QSK19. QSK38. QSK50需要满足中华非发展其三时段及北美地区Tier2. Tier 3排污相关法律法规规范。

Electric fuel injection engines (QSNT,QSK19,QSK38,QSK50) meet the Tier3 emission regulations for China non-road vehicles and Tier2 & Tier3 emission regulations of North America.

零备品备件而犯性好， 热车机执行及定期检查护肤保养便于，生产低成本投入。Good availbility of spare parts, smooth engine operation, convenient engine maintenance and low cost.

发动机规格Engine Specifications

耗油率范围内 Power Range   224-310KW结构类型 Type   直列/六缸/四冲程/四气门  In-ine/6-Cylinder/4-Stroke/4-Valve缸径x冲程 BoreX Stroke  125X 147mm排量 Displacement   11L外观简约时尚图片尺寸 Dimension  长X宽X高(LXWX H) 1360 x 833X 1068 mm净效果 Dry Weight   940kg

224-310KW康明斯电站用发起机的优势特点：量小， 减小比低， 格栅板自然空气煮沸，易进行，中国电信车载多媒体电压的最佳的选择。Compact size, high compression ratio, gile heated by air, easy for start-up, the first option of mobile vehicle power supply.

推荐机型Engine Models Recommended

启行为型号规格	实用热效率(kW)Prime Power	备品电率kW)Standby Power
MTA11-G2	224	246
MTAA11-G3	282	310
